【产品介绍】
l 适配器外观平滑、洁净、无油污及毛刺，无伤痕和裂痕
Appearance of adapter must be smooth and clean. It has no oil, burrs, scars and crack；
l 适配器外观颜色鲜明、一致性好
The color of adapter must be bright in good consistency；
l 各零部件组合须平整，插头与适配器的插入和拔出须平顺、轻松、卡子有力；
All parts of adapter can assembly well without difficulty, it should be easy and
comfortable to plug in and pull out connector from adapters, the clip should be
powerful.
l 模式：单模
Modes：SM ；
l 高精密陶瓷套管；
sleeve in high precision；
l 所有材料满足 RoHS 要求；
all material meets RoHS
l 低插入损耗；low insertion loss
l 重复性好； good repeatability
l 互换性好；good interchangeability
l 安装方便； Easy installation
l 温度稳定性好；good temperature stability
l 光纤通信系统；Optical fiber communication system
l 有线电视网络；cable television network
l 局域网,广域网；LAN,WAN
l 光纤接入网；Optical fiber access network
l 视频传输；video transmission
|
项目 Project |
指标 Values |
||
|
参照标准 Reference standard |
YD/T 1272.4-2007 |
||
|
插入损耗 Insertion loss |
≤0.2dB |
||
|
各种试验后的插损变化量 IL change absolute value |
低温 low temperature |
温度：-25℃ 时间：96小时 Temperature: -25℃ Duration: 96 h |
≤0.2dB |
|
高 温 high temperature |
温度：70℃ 时间：96小时 Temperature: 70℃ Duration: 96 h Temperature change rate: 1℃/min |
≤0.2dB |
|
|
湿 热 Hot and humid |
温度：40℃ 温度：90%~95% 时间：96小时 Temperature: 40℃ Humidity: 90%~95% Duration: 96h Temperature change rate: 1℃/min |
≤0.2dB |
|
|
温度循环 Temperature cycle
|
温度：-10℃ to + 60℃ 时间：96小时 循环次数：12 Temperature: -10℃ to + 60℃ Duration: 96h Cycle times:12 Temperature change rate: 1℃/min |
≤0.2dB |
|
|
重复性 repeatability |
重复插拔10次 Insertion pull times:10 |
≤0.2dB |
|
|
机械耐久性 Mechanism durability |
插拔次数：500次 Insertion times: 500 cycles |
≤0.2dB |
|
|
锁紧机构抗拉强度 Tensile strength Of coupling mechanism |
50N/10 Minute |
≤0.2dB |
|
|
插拔力 pull-out force |
≤19.6.N |
|
材料阻燃性能 Flame resistance |
UL94-V0 |
|
工作温度 work temperature |
-25℃～+70℃ |
|
储存温度 storage temperature |
-25℃～+70℃ |
|
部件名称 parts Name |
数量 Qty |
材质 Requirement |
|
外壳 Body(housing) |
2 |
ABS |
|
防尘帽 Dust cap |
4 |
PVC |
|
套管 Sleeve |
2 |
Zirconia Ceramic |
